AKD Benutzerhandbuch | 24.12.7 DOUT1.STATEU AND DOUT2.STATEU

24.12.7 DOUT1.STATEU AND DOUT2.STATEU

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-01-01-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
DOUT1.STATEU
DOUT2.STATEU
Fieldbus Index/Subindex
Modbus
Description
Set the state of the digital output node as follows:
0 = deactivated
1 = activated
DOUT1.STATEU and DOUT2.STATEU are used when DOUT1.MODE to DOUT2.MODE (S. 547) = 0
(user mode).
Related Topics
552 KOLLMORGEN | Mai 2014
R/W Parameter
Sets the state of the digital output
node.
N/A
0 to 1
0
Integer
Variant Supported
Paramter Fieldbus
Profinet
sercos ® III
Profinet
sercos ® III
204 DOUT1.STATEU
214 DOUT2.STATEU
AKD-C and AKD-N only support DOUT1.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Address Attributes Signed?
Byte
2102
2 Octets
No
Byte
2107
2 Octets
Is 64 bit? Attributes Signed? Object Start Version
No 8 bit No M_01-03-00-000
