AKD Benutzerhandbuch | 24.2.2 AIN.DEADBAND

24.2.2 AIN.DEADBAND

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variant Support
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 2
Description
AIN.DEADBAND sets the deadband of the analog input signal. When AIN.DEADBANDMODE is set to
0, and the value of the analog input is less than the value of AIN.DEADBAND, the analog command will
be 0. When the analog input is greater or equal to the AIN.DEADBAND, then the analog command will be
generated using the scaling specified.
When AIN.DEADBANDMODE is set to 1, the analog command is 0 if the input is less than the deadband
value. When the input is greater than the deadband, the output is equal to (Input - Deadband) * Scaling.
Below are illustrations of this behavior.
NV Parameter
Sets the analog input signal dead-
band.
V
0 to 12.5 V
0 V
Float
Variant Supported
Address Attributes Signed?
Word
2001 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
16 bit No M_01-03-00-000
