AKD Benutzerhandbuch | 24.28.2 MOTOR.BRAKE

24.28.2 MOTOR.BRAKE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
AKD BASIC Information
Data Type
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 482
Description
The MOTOR.BRAKE parameter notifies the firmware whether a brake exists or not. It does not apply or
release the brake. If a brake is found to be present, the firmware considers hardware indications regarding
the brake circuits (such as open circuit or short circuit). If a brake does not exist, then the firmware ignores
the hardware indications since they are irrelevant.
NV Parameter
Sets the presence or absence of a motor
brake.
N/A
0 to 1
0
Boolean
N/A
Integer
Variant Supported
Index/Subindex Object Start Version
3587h/0
Address Attributes Signed?
Byte
2241 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
8 bit No M_01-03-00-000
KOLLMORGEN | Mai 2014 889
