AKD Benutzerhandbuch | 24.2.7 AIN.PSCALE
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 8
Description
AIN.PSCALE is an analog position scale factor that scales the analog input (AIN.VALUE (S. 414)) for
DRV.OPMODE (S. 640) = 2 , DRV.CMDSOURCE (S. 573) = 3 (analog position mode).
Related Topics
Analogeingang (S. 128)
Block Diagram for Position/Velocity Loop (pg 1)
413 KOLLMORGEN | Mai 2014
Variant Supported
Index/Subindex Object Start Version
3472h/0
Address Attributes Signed?
DWord
2004 Yes
8 Octets
Yes
Yes
Yes
Yes
No
No
M_01-00-00-000
64 bit Yes M_01-03-00-000
