AKD Benutzerhandbuch | 24.33.20 REC.TRIGVAL
24.33.20 REC.TRIGVAL
General Information
Type
Description Sets the trigger value.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.TRIGVAL is the value that must be met by REC.TRIGPARAM for the trigger to occur. The units of
this parameter are set according to the units of REC.TRIGPARAM.
Related Topics
Oszilloskop (S. 250)
R/W Parameter
The units of the parameter are chosen according to the unit type.
0 to 2
0
Integer
REC.TRIG (S. 1045), REC.TRIGPARAM, REC.TRIGVAL, REC.TRIG-
SLOPE, REC.TRIGPOS
M_01-00-00-000
Variant Supported
Address Attributes Signed?
DWord
2365 Yes
8 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
