AKD Benutzerhandbuch | 24.29.20 MT.TVELWND
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 564
Description
Within DRV.MOTIONSTAT (S. 631), MT.TVELWND is used to indicate that the target velocity of a
motion task has been reached. DRV.MOTIONSTAT (S. 631) displays a "Target Velocity Reached" bit as
soon as the following statement becomes true:
(target velocity – MT.TVELWND) < actual velocity < (target velocity + MT)
Related Topics
Fahraufträge (S. 175)
Variant Supported
Index/Subindex Object Start Version
3856h/0
Parameter Address Attributes Signed?
MT.TVELWND_32 2282
No 32 bit
Yes
No
M_01-00-00-000
DWord
No
8 Octets
No M_01-03-00-000
