AKD Benutzerhandbuch | 24.32.1 PLS.EN

24.32.1 PLS.EN

General Information
Type
Description Enables programmable limit switch (PLS).
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 618
Description
PLS.EN is a bit variable which determines the mode of an individual PLS. Eight PLSs are available in the
drive.
Example
1012 KOLLMORGEN | Mai 2014
R/W Parameter
N/A
0 to 255
0
Integer
PLS.MODE (S. 1014), PLS.RESET, PLS.STATE, PLS.UNITS, PLS.P1 to
PLS.P8, PLS.WIDTH1 to PLS.WIDTH8, PLS.T1 to PLS.T8
M_01-02-03-000
Variant Supported
Index/Subindex Object Start Version
34A3h/1
Address Attributes Signed?
Word
2309 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-02-03-000
16 bit No M_01-03-00-000
