AKD Benutzerhandbuch | 24.16.19 FB1.OFFSET
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 290
Description
FB1.OFFSET is a value added to the position feedback (PL.FB (S. 992)).
Example
If PL.FB is 10 deg and FB1.OFFSET is set to –10 deg, then the next read of PL.FB will return ~0 deg.
Related Topics
Rückführung 1 (S. 76)| PL.FB (S. 992)
Address Attributes Signed?
DWord
2145 Yes
8 Octets
Yes 64-bits Yes M_01-06-03-000
