AKD Benutzerhandbuch | 24.7.2 CAP0.EN, CAP1.EN

24.7.2 CAP0.EN, CAP1.EN

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter Fieldbus
CAP0.EN
CAP1.EN
Field-
bus
Modbus 56
Description
This parameter enables or disables the related capture engine. After each successful capture event, this
parameter is reset to 0 and must be activated again for the next capture. Also note that CAP0.PLFB,
CAP1.PLFB (S. 489) is set to 0 when this parameter is set to 1.
0 = Disable
1 = Enable
480 KOLLMORGEN | Mai 2014
NV Parameter
Enables or disables the related capture
engine.
N/A
0 to 1
0
Boolean
Variant
Address Attributes Signed?
Profinet Byte
2028
sercos ® III
2 Octets
Profinet Byte
2041
sercos ® III
2 Octets
Index/Subindex
CAP0.EN
No
82 CAP1.EN
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
Is 64 bit? Attributes
8 bit
Object
Start
Signed?
Ver-
sion
M_01-
No
03-00-
000
