AKD Benutzerhandbuch | 24.10.5 DIN1.FILTER TO DIN7.FILTER
Fieldbus Index/Subindex
Modbus
Description
This parameter sets the digital input filter configuration for channel x when followed with the values
defined below. DINx.FILTER retrieves this information when not followed by data.
DINX.FILTER
0
DINX.FILTER
1
DINX.FILTER
2
DINX.FILTER
3
Related Topics
Digitale Eingänge und Ausgänge (S. 112)
522 KOLLMORGEN | Mai 2014
918 DIN1.FILTER
920 DIN2.FILTER
922 DIN3.FILTER
924 DIN4.FILTER
926 DIN5.FILTER
928 DIN6.FILTER
930 DIN7.FILTER
Value
The drive digital input channel detects all input signals with
an input pulse width of ≥ 40 ns (no filtering applied).
The drive digital input channel detects all input signals with
an input pulse width of ≥ 10.24 µs, ± 0.64 µs (fast filter
applied).
The drive digital input channel detects all input signals with
an input pulse width of ≥ 163 µs, ± 10.24 µs (standard filter
applied).
The drive digital input channel detects all input signals with
an input pulse width of ≥ 2.62 ms, ± 0.16384 ms (slow filter
applied).
AKD-N only supports DIN1 to DIN3.
Is 64 bit? Attributes Signed?
No 16 bit No
