AKD Benutzerhandbuch | 24.24.13 IL.FOLDWTHRESH

24.24.13 IL.FOLDWTHRESH

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 440
Description
IL.FOLDWTHRESH is the warning level of the current foldback algorithm. When IL.IFOLD (S. 834) drops
below IL.FOLDWTHRESH a warning is generated.
To ensure that the current foldback warning level is never reached, IL.FOLDWTHRESH should be set
well below the continuous current value for both the drive and the motor. You can also set the
IL.FOLDFTHRESH (S. 830) value to zero.
Related Topics
13.3 Stromregelkreis
832 KOLLMORGEN | Mai 2014
NV Parameter
Sets the foldback warning
level.
Arms
0 to 500 Arms
0 A
Float
Foldback
Variant Supported
Index/Subindex Object Start Version
355Ah/0
Address Attributes Signed?
DWord
2220 Yes
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
32 bit Yes M_01-03-00-000
