AKD Benutzerhandbuch | 24.32.8 PLS.WIDTH1 TO PLS.WIDTH8

24.32.8 PLS.WIDTH1 TO PLS.WIDTH8

General Information
Type
Description Programmable Limit Switch Width
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
AKD BASIC Information
Data Type
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
R/W parameter
Depends on UNIT.PROTARY (S. 1120) or UNIT.PLINEAR (S. 1116)
N/A
0
Float
PLS.EN, PLS.RESET, PLS.STATE, PLS.UNITS, PLS.MODE, PLS.P1 TO
PLS.P8, PLS.T1 TO PLS T8
M_01-02-03-000
Integer
Variant Supported
Index/Subindex
34A1h/1 PLS.WIDTH1
34A1h/2 PLS.WIDTH2
34A1h/3 PLS.WIDTH3
34A1h/4 PLS.WIDTH4
34A1h/5 PLS.WIDTH5
34A1h/6 PLS.WIDTH6
34A1h/7 PLS.WIDTH7
34A1h/8 PLS.WIDTH8
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Object Start Version
M_01-02-03-000
KOLLMORGEN | Mai 2014 1027
