AKD Benutzerhandbuch | 24.23.2 HWLS.POSSTATE

24.23.2 HWLS.POSSTATE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 424
Description
HWLS.POSSTATE reads the status of the positive hardware limit switch as follows:
0 = Low
1 = High
Related Topics
R/O Parameter
Reads the status of the positive hardware limit
switch.
N/A
0 to 1
N/A
Integer
HWLS.NEGSTATE (S. 815)
Variant Supported
Address Attributes Signed?
Byte
2212 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
8 bit No M_01-03-00-000
