AKD Benutzerhandbuch | 24.13.45 DRV.LOGICVOLTS
24.13.45 DRV.LOGICVOLTS
General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
DRV.LOGICVOLTS reads the logic voltages data of 1.2 V, 2.5 V, 3.3 V, 5 V, 12 V, –12 V, and 3.3 AV.
Example
Below is an example of the output for this command:
ch0 = 1.2V
ch1 = 2.5V
ch2 = 3.3V
ch3 = 5V
ch4 = 12V
ch5 = -12V
ch6 = 3.3AV :3300 mv
ch7 = R ohm :100000 ohm
627
KOLLMORGEN | Mai 2014
R/O Parameter
Reads the logic volt-
ages.
mv , Ω
N/A
N/A
String
Variant
Supported
: 1211 mv
:2488 mv
:3274 mv
:4950 mv
:11892 mv
:-11912 mv
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
