AKD Benutzerhandbuch | 24.28.14 MOTOR.KE

24.28.14 MOTOR.KE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-03-06-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1216
Description
MOTOR.KE defines the back EMF constant for the motor. The back EMF constant defines how much
voltage is generated at the motors coils. The relationship between MOTOR.KE and speed is described by
the following equation:
Coil Voltage = MOTOR.KE * VL.FB
VL.FB is in units of krpm for rotary motors and in units of m/s for linear motors.
The maximum speed for interior permanent magnet motors (IPM) is determined by MOTOR.KE and
VBUS.VALUE. An overspeed fault is generated if MOTOR.TYPE is set to 6 (IPM) and VL.FB *
MOTOR.KE exceeds VBUS.VALUE.
906 KOLLMORGEN | Mai 2014
NV Parameter
Sets the motor back EMF con-
stant.
Vpeak/krpm for Rotary Motors
Vpeak/m/s for Linear Motors
0.0 to 100,000
0
Float
N/A
Variant
Address Attributes Signed?
DWord
2608
4 Octets
No
This parameter is automatically configured for Kollmorgen motors when
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
32 bit No
