AKD Benutzerhandbuch | 24.17.11 FB2.SOURCE

24.17.11 FB2.SOURCE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 988
Description
This parameter sets the secondary feedback source to be either the EEO connector (X9) or the high speed
opto inputs on the I/O Connector (X7) as follows:
0 = None
1 = Feedback Source X9 (EEO connector)
2 = Feedback Source X7 (High Speed Opto Inputs on the I/O Connector)
FB2 5V Power Supply Notes:
If FB2.SOURCE = 0 or 2 (X7), the 5V power supply will remain off.
If FB2.SOURCE = 1 (X9) the FB2 5V power supply will remain on unless a short is detected. This is use-
ful for encoder types that may require calibration.
730
KOLLMORGEN | Mai 2014
R/W Parameter
Sets the source for the second feedback input. Choices are the EEO con-
nectors (X9) which are RS485 inputs, or the X7 connector's high speed opto
inputs (pins 9 and 10).
N/A
0 to 2
0
Integer
FB2.ENCRES, FB2.MODE, PL.FBSOURCE (S. 994)
M_01-03-00-000
Variant
Supported
Address Attributes Signed?
Word
2494
No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
16 bit
No
