AKD Benutzerhandbuch | 24.7.13 CAP0.TRIGGER, CAP1.TRIGGER

24.7.13 CAP0.TRIGGER, CAP1.TRIGGER

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Paramter
CAP0.TRIGGER
CAP1.TRIGGER
Fieldbus Index/Subindex
78
Modbus
104
Description
This parameter specifies the trigger source (capture input signal).
Trigger Source
NV Parameter
Specifies the trigger source for the position cap-
ture.
N/A
0 to 11
0
U8
Variant
Index/Subindex
3460h/1 CAP0.TRIGGER
3460h/2 CAP1.TRIGGER
Fieldbus Address Attributes Signed?
Profinet
2039
sercos ® III
Profinet
2052
sercos ® III
Is 64 bit? Attributes Signed? Object Start Version
CAP0.TRIGGER
No
CAP1.TRIGGER
Input Name
0 General Input 1
1 General Input 2
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Object Start Version
M_01-00-00-000
Byte
2 Octets
No
Byte
2 Octets
8 bit No M_01-03-00-000
