AKD Benutzerhandbuch | 24.19.2 FBUS.PLLSTATE

24.19.2 FBUS.PLLSTATE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-02-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
FBUS.PLLSTATE returns the status of the phase locked loop (PLL). The PLL states are as follows:
PLL State
PLL not acti-
vated
PLL acti-
vated, but
unlocked
PLL acti-
vated and
locked
For more information, see the AKD CANopen Manual, Phase Locked Loop.
749 KOLLMORGEN | Mai 2014
R/O Parameter
Returns the status of the PLL
N/A
N/A
N/A
N/A
FBUS.PARAM1 TO FBUS.PARAM10 (S. 745), Fieldbus doc-
umentation
Variant Supported
This state is set using FBUS.PARAM02. Not each fieldbus or operation mode
needs synchronization.
The PLL is activated but has not yet been locked successfully. This state is
related to the fieldbus master, as well as to the fieldbus mode of operation.
PLL is fully operational and locked
Yes
Yes
Yes
Yes
No
Yes
Yes
Yes
Yes
Yes
Yes
Description
