AKD Benutzerhandbuch | 24.3.6 AIN2.VALUE

24.3.6 AIN2.VALUE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-06-03-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1250
Description
AIN2.VALUE reads the analog input 2 value after the value is filtered (as shown in the Analog Input Block
Diagram).
Related Topics
Analogeingang (S. 128)
AIN2.OFFSET (S. 424)
AIN2.ZERO (S. 426)
Block Diagram for Position/Velocity Loop
R/O Parameter
Reads the value of the analog input 2 sig-
nal.
V
-12.5 to +12.5 V
N/A
Float
Index/Subindex Object Start Version
3470h/4
3509h/0
No 16 bit
M_01-00-00-000
No M_01-06-03-000
KOLLMORGEN | Mai 2014 425
