AKD Benutzerhandbuch | 24.33.18 REC.TRIGSLOPE
24.33.18 REC.TRIGSLOPE
General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.TRIGSLOPE sets the recorder trigger slope. This parameter is only used when REC.TRIGTYPE =
2 or 3.
Related Topics
Oszilloskop (S. 250)
1050 KOLLMORGEN | Mai 2014
R/W Parameter
Sets the trigger slope.
0 = Negative
1 = Positive
0 to 1
0
Integer
REC.TRIG, REC.NU-
MPOINTS
Variant Supported
Address Attributes Signed?
Byte
2363 No
2 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
