AKD Benutzerhandbuch | 24.12.3 DOUT.STATES

24.12.3 DOUT.STATES

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Data Type
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 194
Description
DOUT.STATES reads the states of the digital output(s). The leftmost bit represents DOUT1 and the right-
most bit represents DOUT2.
Related Topics
Digitalausgänge (S. 118)
546 KOLLMORGEN | Mai 2014
R/O Parameter
Reads the state of the digital output
(s).
N/A
0 to 11
N/A
String
AKD BASIC Information
Integer
Variant
No
AKD-C only reads the state of DOUT1.
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
8 bit No M_01-03-00-000
