AKD Benutzerhandbuch | 24.24.33 IL.MIFOLD

24.24.33 IL.MIFOLD

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 470
Description
IL.MIFOLD sets the output of the motor foldback algorithm. It is an artificial current, which can be higher
or lower than the motor peak current. When IL.MIFOLD becomes lower than the existing current limit
(IL.LIMITP (S. 848)) it becomes the active current limit.
IL.MIFOLD decreases when the actual current is higher than motor continuous current and increases (up
to a certain level) when the actual current is lower than the motor continuous current.
Related Topics
13.3 Stromregelkreis
854 KOLLMORGEN | Mai 2014
R/O Parameter
Sets the motor foldback current
limit.
A
0 to 2147483.647 A
N/A
Float
Foldback
Variant Supported
Index/Subindex Object Start Version
35A4h/0
Address Attributes Signed?
DWord
2235 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
32 bit No M_01-03-00-000
