AKD Benutzerhandbuch | 24.28.23 MOTOR.PITCH

24.28.23 MOTOR.PITCH

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 502
Description
This parameter defines the pole-to-pair pitch for the linear motor in micrometers.
Related Topics
Motor (S. 71)
NV Parameter
Sets the motor pitch.
µm
1,000 to 1,000,000
µm
1.000 µm
Integer
N/A
Variant Supported
Address Attributes Signed?
DWord
2251 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
32 bit No M_01-03-00-000
KOLLMORGEN | Mai 2014 917
