AKD Benutzerhandbuch | 24.24.17 IL.IVFB

24.24.17 IL.IVFB

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 448
Description
IL.IVFB is an offset value that is added to the measured current in the u-winding of the motor. This value is
used for compensating for an error in the current measurement. The drive measures 256 times the current
in the u-winding when powering-up the drive. Afterwards, the drive calculates the average value of the
measured current and uses this value for the offset value.
Related Topics
Stromregelkreis (S. 149)
R/O Parameter
Sets the sigma-delta measured current in the u-winding of the
motor.
A
± Drive peak current (DRV.IPEAK)
0 A
Float
N/A
Variant Supported
Address Attributes Signed?
DWord
2224 Yes
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
32 bit Yes M_01-03-00-000
