AKD Benutzerhandbuch | 24.18.8 FB3.PIN

24.18.8 FB3.PIN

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-05-011-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
Use FB3.PIN with FB3.POUT (S. 742) to set the user units for FB3.P (S. 738).
Related Topics
Rückführung 1 (S. 76) | FB3.PUNIT (S. 743) | FB3.P (S. 738) | FB3.POUT (S. 742)
NV Parameter
Sets gear IN for FB3.P (S.
738).
N/A
0 to 4,294,967,295
100
Integer
Variant Supported
Address Attributes Signed?
DWord
2826 No
4 Octets
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
