AKD Benutzerhandbuch | 24.16.30 FB1.PUNIT

24.16.30 FB1.PUNIT

General Information
Type
Description
Units
Range
Default Value
Data Type
See Also
Start Version
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1624
Description
FB1.PUNIT sets the position unit for FB1.P.
Value
0
3
Related Topics
FB1.P (S. 696)
706 KOLLMORGEN | Mai 2014
NV Parameter
Sets the unit for FB1.P.
N/A
0, 3
0
U8
N/A
M_01-05-11-000
Variant
Address Attributes Signed?
DWord
2812 No
4 Octets
No
Description
Counts (32.32 format)
(FB1.PIN/FB1.POUT) per revolution.
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
32-bits No M_01-06-03-000
