AKD Benutzerhandbuch | 24.3.3 AIN2.DEADBANDMODE

24.3.3 AIN2.DEADBANDMODE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-06-03-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 1238
Description
When AIN2.DEADBANDMODE is set to 0, and the value of the analog input 2 is less than the value of
AIN2.DEADBAND (S. 421), the analog command will be 0. When the analog input 2 is greater or equal to
the AIN2.DEADBAND, then the analog command will be generated using the scaling specified.
When AIN2.DEADBANDMODE is set to 1, the analog command is 0 if the input is less than the dead-
band value. When the input is greater than the deadband, the output is equal to (Input - Deadband) * Scal-
ing.
Related Topics
Analogeingang (S. 128)
AIN2.DEADBAND (S. 421)
Block Diagram for Position/Velocity Loop (pg 1)
422 KOLLMORGEN | Mai 2014
NV Parameter
Sets the analog input 2 deadband
mode.
N/A
0 to 1
0
Integer
No 16 bit No
