AKD Benutzerhandbuch | 24.12.1 DOUT.CTRL

24.12.1 DOUT.CTRL

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Range
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 190
Description
DOUT.CTRL sets the source of the digital output(s):
0 = Firmware controlled
1 = Fieldbus controlled
Related Topics
Digitalausgänge (S. 118)
544 KOLLMORGEN | Mai 2014
NV Parameter
Sets the source of digital output(s) (firmware or field-
bus).
N/A
0 to 1
0
Boolean
SynqNet Information
1
Variant
Address Attributes Signed?
Byte
2095
2 Octets
No
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
8 bit No M_01-03-00-000
