AKD Benutzerhandbuch | 24.17.5 FB2.MOTORPOLES

24.17.5 FB2.MOTORPOLES

General Information
Type
Description
Units
Range
Default Value
Data Type
Start Version
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
This parameter sets the number of motor poles associated with FB2. When multiple motors are driven by
a single AKD, this allows different motor configurations to be saved for each value of IL.FBSOURCE (S.
827).
When IL.FBSOURCE is set to 1, the value of FB2.MOTORPOLES will overwrite the current value of
MOTOR.POLES (S. 918).Additionally, while IL.FBSOURCE = 1, a write to MOTOR.POLES will also
overwrite FB2.MOTORPOLES.
Related Topics
Motor (S. 71)
724 KOLLMORGEN | Mai 2014
NV Parameter
Sets the number of motor poles associated with FB2.
N/A
0 to 510
0
Integer
M_01-11-04-000
Variant Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
