AKD Benutzerhandbuch | 24.10.10 DIN9.STATE to DIN11.STATE

24.10.10 DIN9.STATE to DIN11.STATE

General Information
Type
Description Shows on selected pin if signal is high or low.
Units
Range
Default
Value
Data Type
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Parameter
DIN9.STATE
DIN10.STATE
DIN11.STATE
Fieldbus
Modbus
Description
This parameter allows the user to see the actual level of the input signal, when the IO is set to input mode.
Parameter value is 0 if signal is low and 1 if signal is high. DIOx.INV can affect the value in this register.
This parameter can be read at any time. The value is only guaranteed to correspond to the output on the
X9 connector when DRV.EMUEMODE is set to 10 and the DIOX.DIR is 0.
Related Topics
532 KOLLMORGEN | Mai 2014
NV Parameter
N/A
0 to 1
0
U8
M_01-05-00-000
Variant
Fieldbus Address Attributes Signed?
Profinet
2727
sercos ® III
Profinet
2653
sercos ® III
Profinet
2654
sercos ® III
Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
1454 DIN9.STATE
1306 DIN10.STATE No
1308 DIN11.STATE
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
Byte
2 Octets
Byte
No
2 Octets
Byte
2 Octets
8 bit No M_01-06-03-000
