AKD Benutzerhandbuch | 24.17.3 FB2.MODE

24.17.3 FB2.MODE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed?
Modbus 986
Description
This parameter sets the feedback 2 input type as follows:
0 = Input A/B Signals
1 = Input Step and Direction Signals
2 = Input, up-down signals
Related Topics
Rückführung 2 (S. 85)
FB2.SOURCE
722 KOLLMORGEN | Mai 2014
R/W Parameter
Sets the mode for the second feedback inputs, EEO connector (X9) and high
speed opto inputs (pins 9 and 10 on X7).
N/A
0 to 2
0
Integer
FB2.ENCRES (S. 721), PL.FBSOURCE (S. 994)
M_01-03-00-000
Variant Supported
Address Attributes Signed?
Word
2493 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
16 bit No
