AKD Benutzerhandbuch | 24.31.12 PL.KP

24.31.12 PL.KP

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 604
Description
PL.KP sets the proportional gain of the position regulator PID loop.
Related Topics
PL.ERR (S. 984) | PL.ERRFTHRESH (S. 986) | PL.ERRMODE (S. 988) | PL.ERRWTHRESH (S. 990)
13.5 Positionsregelkreis
NV Parameter
Sets the proportional gain of the position regulator PID
loop.
(rev/s)/rev
0 to 2,147,483.008 (rev/s)/rev
100 rps/rev
Float
PL.KI (S. 1001),
Variant Supported
Index/Subindex Object Start Version
3542h/0
Address Attributes Signed?
DWord
2302 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
32 bit No M_01-03-00-000
KOLLMORGEN | Mai 2014 1002
