AKD Benutzerhandbuch | 24.28.39 MOTOR.VOLTRATED

24.28.39 MOTOR.VOLTRATED

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-03-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1676
Description
This parameter configures the drive for the induction motor's rated voltage as indicated on the nameplate.
MOTOR.VOLTRATED is used to calculate the constant Volts per Hertz characteristics of the drive and
motor.
If MOTOR.AUTOSET = 1 and FB1.MEMVER > 0.01, this parameter will be auto-
matically configured for KOLLMORGEN motors.
Related Topics
NV Parameter
Sets the motor rated voltage.
V
50 to 1,000 V
230 V
U16
MOTOR.VRATED (S. 941), MOTOR.VOLTMIN (S.
938)
Variant Supported
Index/Subindex Object Start Version
3457h/2
Address Attributes Signed?
Word
2838 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-03-00-000
16-bit No M_01-06-03-000
