AKD Benutzerhandbuch | 24.28.16 MOTOR.LDLL

24.28.16 MOTOR.LDLL

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-11-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Descriptio
This parameter is the motor line to line direct axis inductance. It is supported for the IPM motor type
(MOTOR.TYPE = 6).
Related Topics
8.1 Motor | MOTOR.LQLL (S. 912) | IL.KPDRATIO (S. 841)
910 KOLLMORGEN | Mai 2014
NV Parameter
Motor line to line direct axis induct-
ance.
mH
1 to 2^31
17.000
Float
Variant
This parameter is automatically configured for KOLLMORGEN motors when MOTOR.A-
UTOSET = 1.
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
