AKD Benutzerhandbuch | 24.4.5 AOUT.ISCALE

24.4.5 AOUT.ISCALE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-01-01-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 18
Description
AOUT.ISCALE sets the analog current scale factor that scales the analog output (AOUT.VALUE) for
AOUT.MODE = 4 or 5. The value entered is the motor current per 10 V of analog input or output. This
value may be either higher or lower than 100%, but the actual analog I/O will be limited by the application
current limit (IL.LIMITN (S. 847) and IL.LIMITP (S. 848)).
Related Topics
Analogausgang (S. 129)
AOUT.ISCALE (➜ p. 1)
NV Parameter
Sets the analog current scale fac-
tor.
A/V
0.001 to 22.4 A/V
0.001 to 22.4 A/V
Float
Variant Supported
Address Attributes Signed?
DWord
2009 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
32 bit No M_01-03-00-000
KOLLMORGEN | Mai 2014 433
