AKD Benutzerhandbuch | 24.33.19 REC.TRIGTYPE
24.33.19 REC.TRIGTYPE
General Information
Type
Description Sets the trigger type.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.TRIGTYPE sets the type of trigger.
Input values are as follows:
Value
0
1
2
R/W Parameter
0 = immediate
1 = command
2 = parameter
3 = boolean
0 to 2
0
Integer
REC.TRIG (S. 1045), REC.TRIGPARAM, REC.TRIGVAL, REC.TRIGSLOPE
REC.TRIGPOS
M_01-00-00-000
Variant
Address Attributes Signed?
Byte
2364
2 Octets
Recording starts immediately
Recording starts on the next command executed through the TCP/IP. The trigger loca-
tion in the buffer is set according to REC.TRIGPOS.
Recording starts per the values of REC.TRIGPARAM, REC.TRIGVAL, REC.TRIG-
SLOPE, and REC.TRIGPOS.
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Description
