24.7.1 CAP0.EDGE, CAP1.EDGE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter
CAP0.EDGE
CAP1.EDGE
Field-
bus
Modbus 54
Description
The filtered trigger source is monitored for rising edge, falling edge, or both edges. The event mode logic
may ignore the precondition edge detection; however, the trigger always uses edge detection.
The precondition logic has an identical feature controlled by CAP0.PREEDGE, CAP1.PREEDGE (S.
491).
478 KOLLMORGEN | Mai 2014
NV Parameter
Selects the capture edge.
N/A
1 to 3
1
U8
Variant
Fieldbus Address Attributes Signed?
Profinet
2027
sercos ® III
Profinet
2040
sercos ® III
Index/Subindex
CAP0.EDGE
No
80 CAP1.EDGE
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Byte
2 Octets
No
Byte
2 Octets
Is 64 bit? Attributes
8 bit
Object
Start
Signed?
Ver-
sion
M_01-
No
03-00-
000
