AKD Benutzerhandbuch | 24.4.9 AOUT.VALUE

24.4.9 AOUT.VALUE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 28
Description
AOUT.VALUE reads the analog output value.
Related Topics
Analogausgang (S. 129)
R/O Parameter
Reads the analog output
value.
V
–10 to +10 V
0
Float
Variant Supported
Index/Subindex Object Start Version
3470h/2
Address Attributes Signed?
DWord
2014 Yes
8 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
M_01-00-00-000
64 bit Yes M_01-03-00-000
