AKD Benutzerhandbuch | 24.7.5 CAP0.FILTER, CAP1.FILTER

24.7.5 CAP0.FILTER, CAP1.FILTER

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version
End Version
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter
CAP0.FILTER
CAP1.FILTER
Field-
bus
Modbus 60
Description
These parameters are not functional in M_01-03-00-000. In future releases, you can use DINx.FILTER to
select a filter on the input channel.
Related Topics
DIN1.FILTER TO DIN7.FILTER (S. 521)
