AKD Benutzerhandbuch | 24.28.36 MOTOR.VMAX

24.28.36 MOTOR.VMAX

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 522
Description
This parameter sets the maximum motor mechanical speed. The value 1.2 x MOTOR.VMAX becomes
the overall overspeed fault threshold (VL.VFTHRESH) if it is less than the user overspeed fault threshold
(VL.THRESH), and for MOTOR.TYPE = 6 if it is less than the motor back EMF overspeed threshold
((1.02 x 1000 x VBUS.OVFTHRESH) / (MOTOR.KE x sqrt(2))).
Related Topics
8.1 Motor | VL.THRESH (S. 1178) | VL.VFTHRESH (S. 1180)
936 KOLLMORGEN | Mai 2014
NV Parameter
Sets the maximum motor
speed.
rpm
100 to 40,000 rpm
3,000 rpm
Integer
Variant Supported
Index/Subindex Object Start Version
35A3h/0
Address Attributes Signed?
Word
2261 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
16 bit No M_01-03-00-000
