AKD Benutzerhandbuch | 24.24.6 IL.DFB

24.24.6 IL.DFB

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-11-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
This parameter displays the measured, de-rotated d-component current value of the motor. This param-
eter is commonly used with IPM motors (MOTOR.TYPE = 6), where the d-component current is con-
trolled for closed loop current regulation.
824 KOLLMORGEN | Mai 2014
R/O Parameter
Reads the actual value of the d-component cur-
rent.
Arms
± Drive peak current (DRV.IPEAK)
N/A
Float
N/A
Variant Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
