AKD Benutzerhandbuch | 24.32.7 PLS.UNITS

24.32.7 PLS.UNITS

General Information
Type
Description Sets programmable limit switch (PLS) units.
Units
Range
Default
Value
Data Type
See Also
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 674
Description
PLS.UNITS is a bit variable which determines the behavior of the eight PLSs available in the drive. This
parameter is used to select the units for the PLS pulse.
Examples
1024 KOLLMORGEN | Mai 2014
R/W parameter
N/A
0 to 255
0
Integer
PLS.EN (S. 1012), PLS.RESET (S. 1018), PLS.STATE (S. 1020), PLS.MODE
(S. 1014), PLS.P1 TO PLS.P8 (S. 1016)PLS.WIDTH1 TO PLS.WIDTH8 (S.
1027), PLS.T1 TO PLS.T8 (S. 1022)
M_01-02-03-000
Variant Supported
Index/Subindex Object Start Version
34A4h/0
Address Attributes Signed?
Byte
2337 No
2 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-02-03-000
8 bit No M_01-03-00-000
