AKD Benutzerhandbuch | 24.18.3 FB3.MODE

24.18.3 FB3.MODE

General Information
Type
Description
Units
Range
Default Value
Data Type
See Also
Start Version
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Modbus
Description
This parameter selects the type of feedback connected to X9. The position is reported as the tertiary feed-
back position, by FB3.P.
This parameter is only supported on drives with model numbers similar to AKD-x-xxxxx-NBxx-xxxx.
735 KOLLMORGEN | Mai 2014
NV Parameter
Selects the type of feedback connected to X9.
N/A
0
0
Integer
NA
M_01-04-15-000
Variant
Address Attributes Signed?
Word
2522
2 Octets
Fieldbus Index/Subindex
1044
Value Feedback
0 Endat 2.2 Feedback Device
Supported
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
