AKD Benutzerhandbuch | 24.33.4 REC.GAP

24.33.4 REC.GAP

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.GAP specifies the gap between consecutive samples. The recording base rate is 16 kHz, thus a
gap of 1 means that a sample is recorded every 62.5 µs.
Related Topics
Oszilloskop (S. 250)
R/W Parameter
Specifies the gap between consecutive sam-
ples.
N/A
1 to 65,535
1
Integer
REC.TRIG (S. 1045)
Variant Supported
Address Attributes Signed?
Word
2356 No
2 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
