AKD Benutzerhandbuch | 24.10.4 DIN.STATES

24.10.4 DIN.STATES

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Range
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Description
DIN.STATES reads the states of the digital inputs. The leftmost bit represents digital input 1 (DIN1) and
the rightmost bit represents digital input 7 (DIN7).
Related Topics
Digitale Eingänge und Ausgänge (S. 112)
520 KOLLMORGEN | Mai 2014
R/O Parameter
Reads the digital input
states.
N/A
0000000 to 1111111
N/A
String
AKD-N Information
000 to 111
Variant
AKD-N only supports DIN1 to DIN3.
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
