AKD Benutzerhandbuch | 24.13.10 DRV.DBILIMIT

24.13.10 DRV.DBILIMIT

General Information
Type
Description Sets the maximum amplitude of the current for dynamic braking.
Units
Range
Default
Value
Data Type
Start Ver-
sion
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
EtherCAT COE and CAN-
open
Fieldbus
Profinet
sercos ® III
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 228
Description
This parameter sets the maximum amplitude of the current for dynamic braking.
Example
Setting DRV.DBILIMIT to 2 limits the dynamic brake current to 2 Arms.
Related Topics
12.9 Kontrollierter Stopp
24.9 CS Parameters
NV Parameter
Arms
0 to minimum of drive peak current (DRV.IPEAK) and motor peak current
(MOTOR.IPEAK).
Minimum of drive continuous current (DRV.ICONT) and motor continuous cur-
rent (MOTOR.ICONT).
Float
M_01-00-00-000
Variant Supported
Index/Subindex Object Start Version
3444h/0
Address Attributes Signed?
DWord
2114 No
4 Octets
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
M_01-00-00-000
32 bit No M_01-03-00-000
