AKD Benutzerhandbuch | 24.7.11 CAP0.STATE, CAP1.STATE

24.7.11 CAP0.STATE, CAP1.STATE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter
CAP0.STATE
CAP1.STATE
Field-
bus
Mod-
bus
Description
When enabling the capture (CAP0.EN, CAP1.EN (S. 480)), this parameter is set to 0 until the next event
is captured.
0 = Not captured or Capture Disabled
1 = Captured
Related Topics
R/O Parameter
Indicates whether or not trigger source was cap-
tured.
N/A
0 to 1
0
Integer
Variant
Fieldbus Address Attributes Signed?
Profinet
2037
sercos ® III
Profinet
2050
sercos ® III
Index/Subindex
74 CAP0.STATE
100 CAP1.STATE
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
Byte
2 Octets
No
Byte
2 Octets
Is 64 bit? Attributes
No 8 bit
Object
Start
Signed?
Ver-
sion
M_01-
No
03-00-
000
