AKD Benutzerhandbuch | 24.5.2 AOUT2.MODE

24.5.2 AOUT2.MODE

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-06-03-000
Variants Supported
Supported by any AKD with extended IO.
Fieldbus Information
Fieldbus Index/Subindex Is 64 bit? Attributes Signed? Object Start Version
Modbus 1276
Description
AOUT2.MODE sets the analog output functionality.
Mode 0: User variable. The analog output 2 signal is determined by the user (using AOUT.VALUEU (S.
448)).
Example
You can use AOUT.MODE and AOUT.VALUEU to configure an output signal as follows:
-->AOUT.MODE 0
-->AOUT.VALUEU 5
-->AOUT.VALUEU 4.33
Related Topics
Analogausgang (S. 129)
NV Parameter
Sets the analog output 2
mode.
N/A
0
0
Integer
No 16 bit No M_01-06-03-000
KOLLMORGEN | Mai 2014 445
