AKD Benutzerhandbuch | 24.12.5 DOUT1.PARAM AND DOUT2.PARAM

24.12.5 DOUT1.PARAM AND DOUT2.PARAM

General Information
Type
Description
Units
Range
Default
Value
Data Type
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Paramter
DOUT1.PARAM
DOUT2.PARAM
Fieldbus Index/Subindex
Modbus
Description
Set the extra parameter needed for the digital output's calculations.
AKD-C and AKD-N only support DOUT1.
Range
DOUTx.PARAM is used for various Digital Output modes. This causes the parameter's range to change
based on the current Digital Output mode selected with the corresponding DOUTx.MODE.
Below is a list of the possible range for each Digital Output Mode.
NV Parameter
Sets extra parameters for the digital output(s).
N/A
0
Note: Range changes based on Digital Output Mode. See
below.
0
Integer
Variant
Fieldbus Address Attributes Signed?
Profinet
2099
sercos ® III
Profinet
2104
sercos ® III
198 DOUT1.PARAM
208 DOUT2.PARAM
Supported
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
DWord
8 Octets
Yes
DWord
8 Octets
Is 64 bit? Attributes Signed? Object Start Version
Yes 64 bit Yes M_01-03-00-000
KOLLMORGEN | Mai 2014 549
