AKD Benutzerhandbuch | 24.33.3 REC.DONE

24.33.3 REC.DONE

General Information
Type
Description
Units
Range
Default
Value
Data Type
See Also
Start Version M_01-00-00-000
Variants Supported
AKD Base
AKD with Position Indexer
AKD EtherCAT
AKD CANopen
AKD BASIC
AKD SynqNet
AKD EtherNet/IP
AKD Profinet
AKD sercos ® III
AKD-N
AKD-C
Fieldbus Information
Fieldbus
Profinet
sercos ® III
Description
REC.DONE indicates that the recorder has finished recording. This value is reset to 0 when the recorder
trigger is set. The drive also resets this value when the recording has finished or when REC.OFF is
executed.
Related Topics
Oszilloskop (S. 250)
1032 KOLLMORGEN | Mai 2014
R/O Parameter
Checks whether or not the recorder has finished record-
ing.
N/A
0 to 1
N/A
Integer
REC.ACTIVE, REC.OFF
Variant Supported
Address Attributes Signed?
Byte
2355 No
2 Octets
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
